Propeller Performance Measurement System
This dedicated test system precisely measures propeller parameters such as rotational speed, thrust, and torque to analyze aerodynamic performance and efficiency. It verifies the design to ensure optimal thrust output tailored to the characteristics of ea
-
Equipment Details
-
Key Feature
- Test Category: Propeller Performance Measurement
- Performance and durability testing of motor–propeller electric propulsion systems used in UAM.
- Integrated test environment for evaluating thrust, vibration, durability, and control performance of propeller–motor systems, supported by a low-noise design chamber.
-
Specification
-
Electric Propulsion System Test Equipment
Load Cell ~ 500kg Torque Sensor ~1500 Nm RPM Sensor ~30,000 rpm Accelerometer Sensor 100mV/g, ±500g Propeller Approx. 2.5 m diameter Configuration Single-axis (single) & coaxial counter-rotation Test Factor Thrust, torque, rotational speed, vibration, responsiveness, durability Additional Equipment Control/monitoring system, DAQ, calibration jig, power supply unit, test table, etc. -
Electric Propulsion System Test Chamber
Chamber Size 9.5m(W) X 30m(L) X 14m(H) Test Section 9.2m(W) X 18m(L) X 6.7m(H) Noise level ~ 60dB (at Outside) Additional Equipment Hoist, base plate, indoor acoustic absorption/damping facilities, etc.
-
-
